Scotch Yoke Pneumatic Actuator
>
Customized Single Acting Actuators Aluminum Alloy Double Acting Actuator
|
Customized Single Acting Actuators Aluminum Alloy Double Acting Actuator
| Place of Origin | China |
| Brand Name | OEM |
| Certification | CE,ATEX,ISO9001 |
| Model Number | B08-B4 |
Product Details
Name:
Single Acting Actuators
Material:
Aluminum Alloy
Structure:
Scotch Yoke
Application:
Automatic Control Valve
Power:
Pneumatic
Temperature:
Normal Temperature,Low Temperature,High Temperature
Media:
Hydraulic Oil Or Water
Color:
Blue,gray,according To Customer's Requirements,customized
Size:
32 To 400
Highlight:
Customized Single Acting Actuators
,Aluminum Alloy Double Acting Actuator
,Double Acting Actuator Customized
Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
10-2000USD
Packaging Details
Foam+Carton Box+Wooden Case
Delivery Time
3-7 days
Payment Terms
T/T
Supply Ability
1000pcs per day
Product Description
Customized Single/Double Acting Aluminum Alloy Scotch Yoke Pneumatic Actuator
High-performance pneumatic actuator featuring scotch yoke mechanism for high torque applications in valve automation systems.
Product Specifications
| Attribute | Value |
|---|---|
| Type | Double Action / Single Action |
| Material | Aluminum Alloy |
| Structure | Scotch yoke |
| Application | Automatic control valve |
| Power | Pneumatic |
| Temperature Range | Normal Temperature, Low Temperature, High Temperature |
| Media | Hydraulic oil or water |
| Color Options | Blue, gray, or customized |
Key Features
- Rotary Angle: 0~90 degree
- Working Pressure: 2~8bar
- Surface Treatment: Hard anodizing for enhanced durability
- Multiple temperature ranges:
- Normal Temperature: -20°C to +80°C
- High Temperature: -15°C to +150°C
- Low Temperature: -40°C to +80°C
- Standard connections: NAMUR, ISO5211 and DIN3337
- Available in multiple colors: grey, black, sky blue, dark blue, red, orange
- External stroke adjustment bolts for precise ±5° adjustment
- Available in both double acting and spring return configurations
Technical Advantages
- Full conformance to ISO5211, DIN3337, VDINDE-3854, and NAMUR standards
- Honed internal surface with hard anodized coating for long service life
- High-quality bearings for low friction and quiet operation
- Pre-compressed load spring for safe mounting and disassembly
- Multiple O-ring materials available for different temperature requirements
- Easy mounting of solenoid valves without additional connecting planks
Applications
Suitable for various demanding environments including flammable, corrosive, dusty, and high-vibration conditions.
- Electric power plants
- Petrochemical facilities
- Oil and gas operations
- Water treatment plants
- Chemical processing
- Mining operations
- Food and pharmaceutical production
Dimensions (mm)
| Model | B06/C06 | B08/C08 | B1/C1 | B2/C2 | B3/C3 | B4/C4 | B5/C5 | B6/C6 |
|---|---|---|---|---|---|---|---|---|
| Dimension 1 | 50x90 | 50x90 | 80x125 | 80x125 | 80x180 | 80x180 | 80x220 | 80x220 |
| Dimension 2 | 80x90 | 80x90 | 80x125 | 100x160 | 120x210 | 120x230 | 140x300 | 180x400 |
| Bolt Size | 4-M8x15 | 4-M12x18 | 4-M12x18 | 4-M12x18 | 4-M12x18 | 4-M12x18 | 4-M12x18 | 4-M12x18 |
| Length | 290 | 372 | 426 | 480 | 583 | 680 | 810 | 1060 |
Product Images
